xDatos del producto
| El color | Blanco | Las normas | Las normas ISO, DIN, ANSI y JIS |
|---|---|---|---|
| Resaltar | surface roughness gauge,surface roughness meter |
||
Descripción de producto
Ra Rz Digital Surface Roughness Tester Platform Pick up for Flat Froove Curve surface
| Image | Description |
| TS55 - Extending Rod, extending rod increases the depth for pickup to enter the part. Length of extending rod is 50mm. | |
| TS90 - Right Angle Rod, change the position of the sensor, mostly use for measure surface of particular groove. | |
| TS100 - Standard Sensor, to measure most of the plane, inclined plane, cone surface, inner hole, groove and other surface roughness, in addition to the standard sensor, other special sensors are needed to measure the measuring platform. | |
| TS110 - Curved Surface Sensor, to measure smooth cylindrical surface which radius is larger than 3mm, for the large radius smooth spherical surface and other surface also can obtain good approximation, need to work with platform TA520 or TA620. | |
| TS120 - Small hole Sensor, to measure the inner surfaces of holes with radius more than 2mm, better to work with platform TA520 or TA620. | |
| TS131 - Deep Groove Sensor, measure groove with width wider than 3mm and depth deeper than 10mm, or the surface roughness of step with height less than 10mm, also can used to measure the planar, cylindrical used with platform,better to work with platform TA520 or TA620. | |
|
TA520 -Metal Substrate Working platform, adjustable height 200mm. With flexible and stable operation and wider application range. Roughness of complex shapes can also be measured. Measurement stand enable the adjustment of the position of stylus to be more precise and measurement to be more stable. If Ra value of measured surface is relatively low, Using measurement platform is recommended. |
|
|
TA620 -Marble Substrate Working Platform, adjustable height 300mm. With flexible and stable operation and wider application range. Roughness of complex shapes can also be measured. Measurement stand enable the adjustment of the position of stylus to be more precise and measurement to be more stable. If Ra value of measured surface is relatively low, Using measurement platform is recommended. |
