Type
|
XHV-5
|
XHV-10
|
XHV-30
|
XHV-50
|
|
Testing Forces
|
N
|
1.961, 2.942, 4.903, 9.807, 19.61, 24.52, 29.42, 49.03
|
2.942, 4.903, 9.807, 19.61, 24.52, 29.42, 49.03, 98.07
|
4.903, 9.807, 19.61, 24.52, 29.42, 49.03, 98.07, 196.1, 294.2
|
9.807, 19.61, 24.52, 29.42, 49.03, 98.07, 196.1, 249.2, 490.3
|
|
KGF
|
0.2, 0.3, 0.5, 1, 2, 2.5, 5
|
0.3, 0.5, 1, 2, 2.5, 3, 5, 10
|
0.5, 1, 2, 2.5, 3, 5, 10, 20, 30
|
1, 2, 2.5, 3, 5, 10, 20, 30, 50
|
|
Carriage Control
|
Automatic(loading/holding-up of loading /unloading)
|
|
Holding Time
|
(0~60)s
|
|
Amplification of the microscope
|
200X, 400X
|
100X, 400X
|
100X, 400X
|
100X, 200X
|
|
Min. graduation value of the test drum wheel
|
0.0625um
|
0.125um
|
|
Testing field
|
1HV~2967HV
|
|
Lens/Indenter switch
|
With Motorized Turret
|
|
Dimension of the X-Y table
|
100X100mm
|
Without
|
|
Movement field of the X-Y table
|
25X25mm
|
Without
|
|
Max. Height of the specimen
|
170mm
|
|
Max. width of the specimen
|
130mm
|
|
Light source
|
Cold light source
|
|
Power
|
110V/220V, 60/50HZ
|
|
Objective
|
The objective 10x, 20x, 40x can be selected according to user’s requirement
|
|
Standard accessories
|
X-Y stage test able
|
Largest test table, “V”Shape test table
|
|
10X Digital Micro Lens, Level, Adjustable Screw, Vicker Hardness Block, RS232 Interface Line (supply according to modle of instrument)
|
|
Dimension
|
535X225X580mm
|
|
Weight
|
Gross weight: 60Kg Net weight:50Kg
|
|
